Product Details:
|
| Product Name: | AT Series Pneumatic Rotary Actuator Double Acting Rack And Pinion Design | Colour: | Black, Gray, Blue, Or As Customers' Requirement |
|---|---|---|---|
| Application: | Ball Valve, Butterfly Valve | Connection: | ISO 5211,DIN 3337 |
| Structure: | Rack And Pinion | Type: | Double Action And Single Action |
| Size: | 32—400 |
AT Series Pneumatic Rotary Actuator Double Acting Rack And Pinion Design
Pneumatic actuator
| Material | Extruded Aluminum alloy |
| Rotary Angle | 0~90 degree |
| Structure | rack and pinion rotary actuator |
| Working Pressure | 2~8bar |
| Surface Treatment | hard anodizing |
| Working Temperature | Normal Temperature: -20ºC(-4°F) ~ 80ºC (+176°F); High Temperature: -15ºC(+5°F) ~ 150ºC (+302°F); Low Temperature: -40ºC(-104°F) ~ 80ºC (+176°F). |
| Connection | NAMUR, ISO5211 and DIN3337 |
| Application | ball valve, butterfly valve, and rotary machine |
| Cup Color | grey, black, sky blue, dark blue, red, orange |
Pneumatic actuator performance, structure and design characteristics
1.Extruded aluminum ASTM6005 body with both internal and external corrosion protection having honed cylinder surface for longer life and low coefficient of friction.
2.Dual piston rack and pinion design for compact construction, symmetric mounting position, high-cycle life and fast operation, reverse rotation can be accomplished in the field by simply inverting the pistons.
3.Multiple bearings and guides on racks and pistons, low friction, high cycle life and prevent shaft blowout.
4.Modular pre-loaded spring cartridge design, with coated spring for simple versatile range, greater safely and corrosion resistance, longer cycle life.
5.Fully machined teeth on piston and pinion for accurate low backlash rack and pinion engagement, maximum efficiency, stainless steel fasteners for long term corrosion resistance.
6.Full conformance to the latest specifications: ISO5211, DIN3337 and NAUMR or product interchange ability and easy mounting of solenoids, limit switches and other accessories.
7.Fluitech has a complete line of rack and pinion actuators, which is the best choice for butterfly and bass valves control. Reliable, reality available products supplying in a broad of operating environments. Our products are NAMUR & ISO5211 compliant and are manufactured under ISO 9001:2000 certification and are CE approved.
AT series Pneumatic Actuator is made of dual pistons driven by racks and pinions. There are two models. One is Dual Acting model, and the other is Spring Return model, which can suit various flammable, corrosive, dusty, strong magnetic field, radiation, vibration corrosive environment indoor or outdoor.
Auto-control in the field of electric power, petrochemical, metallurgy, petroleum, gas, town, construction, drainage, chemical industry, oil refining, mining, power plant, metallurgy, architecture, medicine, food, gas, scientific research, etc.
-1). Our design, material and size are definitely accord with ISO9001:2008, CE Certificate and ATEX Certificate.
-2). Our piston is treated thermal quenching to obtain better strength and prolong using life.
-3). The surface of our actuator body is treated hard anoidizing to against rust and scratch.
-4). We provide with OEM service
-5). Strict quality control
-6). Better quality at a better price
-7). Excellent After-service.
-8). Fast delivery time
